A Swedish-Finnish research group has conducted a comprehensive analysis of all storage options for large-scale compressed hydrogen, including storage vessels, geological storage, and other underground options.
They complemented their qualitative review with an assessment that considered a broad spectrum of technological advances for storing compressed gaseous hydrogen.
“Most of the technologies discussed in this study are immature and under development, which means that the research is still ongoing,” they said. “Furthermore, the infrastructure and facilities behind some of the technologies are massive, which would require significant resources and costs.”
They also noted that storage projects should be big enough to ensure low costs and profitability.
“The lesser the size, the more costly and unrealistic option it would be. Furthermore, geological nature and viability are crucial factors for some technologies,” they warned, in reference to the constraints of the geological options.
Storage vessels
The scientists grouped storage vessels into four categories: pressure vessels made of metals like carbon steel and low-alloy steel, thick load-bearing metal liners based on steel or aluminium, thin metal liners with fibre resin composites, ultra-thin metal liners fully wrapped with fibre resin composites, and linerless fully composite pressure vessels based on fibre-reinforced shells.
The scientists noted the importance of different components such as valves, sensors, and storage containers for this kind of hydrogen storage. They also considered the most common fibre-reinforced composites used for hydrogen storage tanks, including carbon fibres, glass fibres, and glass fibres. They also looked at polyester, phenol, and epoxy resins for manufacturing pressure vessels. They said the latter are the best candidates due to their high mechanical properties and resistance to temperature and corrosion.
They also looked at seamless hydrogen storage vessels in hydrogen fuel stations and multifunctional layered stationary hydrogen storage vessels. The former can be cascaded in multi-vessel assemblies through valves and interconnection piping manifolds, leading to more hydrogen leak points. The latter are considered ideal for large-scale hydrogen storage operating at high pressure, without restrictions on size. The scientists also looked at steel-concrete composite pressure vessels and natural gas metallic vessels.
Geological storage
The Swedish-Finnish group assessed several options for geological hydrogen storage, including depleted oil and gas reservoirs, aquifers, salt caverns, abandoned mines, and rock caverns.
“The geological storage system typically includes injection and withdrawal wells and a confining layer. The injection and withdrawal wells are the devices responsible for getting the hydrogen in and out of the underground geological formations,” they said.
In addition, they assessed the viability of blending hydrogen into natural gas pipelines and underground methanation reactors.
“Despite the benefits of hydrogen injection into the natural gas network, there are also drawbacks that limit the amount of hydrogen (%) that can be injected. Hydrogen embrittlement is one of the main issues concerning pipelines safety and leaking risk,” the scientists said, in reference to the first of the two technologies.
They see the methanation reactors as a potentially good alternative, but they still have concerns about the methane production rate.
“The resulting methane then could be added to the natural gas network, which can provide one big storage that can be accessed by renewable sources that are close to the natural gas grid,” they said.
The academics said that they eventually want to conduct distance assessments for hydrogen transport, storage losses and all uses of stored hydrogen.
“The knowledge of these factors shall help the decision-makers to analyse and identify the tradeoffs among the different factors concerning the different technologies based on case by case requirements that can include specific technical parameters such as discharge or storage size,” they said.
They presented their findings in “Large-scale compressed hydrogen storage as part of renewable electricity storage systems,” which was recently published in the International Journal of Hydrogen Energy. The research group includes academics from Sweden’s KTH Royal Institute of Technology and the Aalto University in Finland.
