Aussie analysis of the fine art of gettering


From pv magazine Global

Scientists at The Australian National University (ANU) have conducted a review of all gettering technologies used in solar wafer manufacturing and offered a comprehensive analysis of the possible gettering sinks and routes for different solar cell architectures.

This technique involves three steps and is utilised during crystal growth to remove containments and other forms of defects in wafers. Through this process, the impurities are initially released into a solid solution and then undergo diffusion through the silicon. Finally, they are trapped in an area away from the active circuit regions of the wafer.

“Gettering is already embedded in most of the current solar cells, through phosphorus diffusion in PERC or PERx devices, as well as in Al-BSF cells,” the research’s corresponding author, Anyao Liu, told pv magazine. “Gettering is also embedded in TOPCon solar cells, although its effectiveness varies a lot, and in silicon heterojunction cells it can be used as a pre-treatment to improve the quality of silicon substrates.

According to her, gettering can be seen as an additional benefit of certain process steps in current industrial cell processing. “However, as cell efficiency increases and becomes increasingly sensitive to traces of metallic impurities, gettering will become an important consideration in cell processing and process parameters of diffusion and polysilicon/oxide fabrication,” she also explained.

In the paper “Gettering in silicon photovoltaics: A review,” published in Solar Energy Materials and Solar Cells, Liu and her colleagues presented all the nomenclatures used in gettering and summarised recent updates to the solubility and diffusivity data of the 3d transition metals used in the process, the so-called getters.

“Many of the gettering techniques in microelectronics are not applicable or effective in silicon PV,” they warned, noting that external gettering is generally more effective in silicon cells, as the silicon wafer bulk represents an important part of the active device region. “The external gettering routes that are most relevant for the state-of-the-art solar cells in mass production are phosphorus diffusion, to a lesser degree boron diffusion, and the emerging P or B-doped poly-Si/SiOx structures,” they also stated.

Phosphorus diffusion is, to date, the most utilised and investigated gettering technique in the solar industry however, its underlying
mechanisms are still controversial and unresolved, according to the research group. Boron diffusion is described as very effective only under unconventional process conditions and is recommended for doped-poly-Si/SiOx structures, which provides a route to simultaneously achieve p+ doping and a strong gettering effect.

The heavily doped c-Si surfaces and/or heavily doped poly-Si/SiOstructures are incorporated in almost all of the high-temperature cell
architectures,” the scientists further explained. “As the two are effective gettering sinks and their underpinning gettering mechanisms are likely the same, a better understanding and identification of the key mechanisms will help to further exploit the benefits of gettering in silicon PV.”

The paper also analysed other capture approaches such as selective doping via ion implantation, state-of-the-art polycrystalline-
silicon/oxide passivating contact structures, dielectric films, aluminium alloying, the use of surface-damaged regions including black silicon, and internal gettering in cast-grown silicon using existing crystallographic defects.
