From pv magazine India
The research team, led by Professor C. Subramaniam, demonstrated that a water electrolysis system that produced 1 ml of hydrogen gas, required 19% lower energy to produce 3 ml of hydrogen in the same time when electrolysis was done in the presence of an external magnetic field. The team achieved this by synergistically coupling the electric and magnetic fields at the catalytic site.
Manipulating heterogeneous electrified interfaces with an external magnetic field (Hext) explicitly mandates the constant presence of Hext for achieving magnetoelectrocatalytic kinetic enhancements. The researchers demonstrated the highest kinetic enhancement of 650% in electrocatalytic hydrogen evolution reaction (HER), without the mandatory presence of Hext.
The key to this effect is the electrocatalytic (carbon-cobalt oxide catalyst) interface that does not require the constant presence of any external magnetic field and can sustain the magnetisation for prolonged time periods. The cobalt-oxide-based catalyst developed by the researchers also provides a cost advantage over platinum (Pt)-based catalysts.
Speaking to pv magazine, Prof. C. Subramaniam said, “There are numerous attempts to fabricate the best electrocatalyst for water splitting at the low material cost, low energy penalty without compromising on the rate of hydrogen generation. Pt-group-based catalysts are the best known in this direction. However, the prohibitive cost of the catalyst is a huge challenge for commercialisation. This led to developing earth-abundant cobalt oxide as catalysts. The cobalt-oxide (Co3O4) nanocubes were dispersed on nanostructured carbon florets as supports to make the final catalyst.”
“Given the kinetics of water splitting is slow with these catalysts, we developed an innovative solution of coupling an external magnetic field to the electrolytic process.”
With this approach, the researchers were able to obtain a 650% increase in current density, 19% lowering of energy required, and a three-fold increase in volumetric hydrogen production rate.
The magnitude of the enhancements achieved is unparalleled. And the intermittent magnetic field required is similar to what a fridge magnet can provide.
“This route can be directly adopted in existing electrolysers without any change in design or mode of operation and one-time exposure of magnetic field for 10 minutes is enough to achieve the high rate of hydrogen production for over 45 minutes,” according to the researchers.
“The intermittent use of an external magnetic field provides a new direction for achieving energy-efficient hydrogen generation. Other catalysts can also be explored for this purpose,” said Prof. Subramaniam. “A basic electrolyser cell of 0.5 nm3/h capacity can be immediately upgraded to a 1.5 nm3/h capacity by replacing the catalysts and supplying the magnetic field,” added Jayeeta Saha and Ranadeb Ball, project researchers and students at IIT Bombay.
Having shown that the method is not very complicated either, the team is now working with an industrial partner to ensure its successful commercialisation.
The research findings are published in Sustainable Chem. Eng Journal of American Chemical Society, 2021.
Author: Uma Gupta
